I. Structure
Base: Thick steel plate, fixed to the ground with anchor bolts, high rigidity, and not easily deformed.
Guide Rails and Slides: Precision linear guide rails + sliders, or roller guide rails; the robot is directly mounted on the slide.
Drive System: Servo motor + reducer + rack and pinion (mainstream), or ball screw; accurate positioning and sufficient power.
Protection: Open (simple), semi-enclosed, fully enclosed (dustproof/welding slagproof/oilproof), equipped with cable drag chain protection.
Stroke: Standard 1-50 meters, infinitely extendable.
II. Core Functions
Expanding Scope: Transforming robots from “fixed-point operation” to continuous operation across multiple workstations.
Cost Reduction and Efficiency Improvement: One robot covers multiple devices, reducing the number of robots and increasing utilization.
Enhancing Flexibility: Quickly switching workstations, adapting to multi-variety, small-batch production.
III. Key Features
Long Stroke: Up to 100 meters+, covering the entire production line.
High Load Capacity: 50kg-15 tons, suitable for both light and heavy-duty robots.
High Precision: Repeat positioning accuracy ±0.05-±0.1mm, stable and reliable.
High Speed: Up to 2m/s (120m/min), high efficiency.
Easy Integration: Compatible with any robot from ABB, KUKA, FANUC, Yaskawa, etc.
IV. Typical Applications
Automotive Manufacturing: Welding, painting, and long-station assembly.
Construction Machinery: Welding, grinding, and handling of large workpieces.
Machine Tool Loading and Unloading: One robot serves multiple lathes/machining centers.
Painting/Palletizing: Long-distance painting, warehouse palletizing/depalletizing.
